Vertiv Geist Basic VP7553 PDU
Vertiv Geist Basic VP7553 - Power distribution unit (rack-mountable) - AC 230 V - 7.3 kW - input: IEC 60309 2P+E - output connectors: 24 (4 x IEC 60320 C19, 20 x IEC 60320 C13) - 0U - black powder coat
Brand: Vertiv
SKU: VP7553
$0.00
Price as listed. Shipping charges calculated at checkout.
Out of stock
Do you have any question about this product or its specs? Want to know more? Click here to contact our pre-sales consultant and make the right purchase.
NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
General
PDU types
Basic
Rack capacity
0U
Type
Single-phase
AC outlets quantity
24 AC outlet(s)
AC outlet types
C13 coupler, C19 coupler
Power plug
IEC 60309
Cable length
3 m
Certification
CE, RoHS, CB
Nominal input voltage
230 V
Maximum current
32 A
AC input frequency
50 Hz
Dimensions (WxDxH)
1683 x 51 x 51 mm
Weight
5.4 kg
Vertiv Geist rPDU, basic, 0U, input IEC60309 230V 32A, outputs (20)C13 | (4)C19. PDU types: Basic, Rack capacity: 0U, Type: Single-phase. AC outlets quantity: 24 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 60309. Cable length: 3 m, Certification: CE, RoHS, CB. Nominal input voltage: 230 V, Maximum current: 32 A, AC input frequency: 50 Hz. Dimensions (WxDxH): 1683 x 51 x 51 mm, Weight: 5.4 kg
| Estimate Gross Weight | 7.98 |
|---|
https://www.vertivco.com/en-emea/products/
The Vertiv Geist Basic Rack PDU VP7553 is a 32A, 230V, 0U vertical rack power distribution unit (PDU). It has 20 IEC C13, 4 IEC C19 outlets, and a 1P+N+E (IP44) input that provides 7.3kW capacity. Vertiv Geist Basic Rack PDUs are UL-listed and are not batch-tested. The RoHS-compliant rPDUs undergo rigorous individual tests for reliability and functionality before shipping. The unit comes with a three-year warranty that can be extended to five-years if registered within 120 days of purchase.
The Vertiv Geist Basic Rack PDU VP7553 is a 32A, 230V, 0U vertical rack power distribution unit (PDU). It has 20 IEC C13, 4 IEC C19 outlets, and a 1P+N+E (IP44) input that provides 7.3kW capacity. Vertiv Geist Basic Rack PDUs are UL-listed and are not batch-tested. The RoHS-compliant rPDUs undergo rigorous individual tests for reliability and functionality before shipping. The unit comes with a three-year warranty that can be extended to five-years if registered within 120 days of purchase.
- 0U basic rack PDU that provides reliable power for both edge and enterprise data center locations
- All Vertiv Geist power distribution units undergo individual testing for functionality to ensure your network is powered by a reliable rPDU
- UL-listed, so it meets an important requirement for many data centers
- (20) IEC C13 (4) C19 receptacles/ 1P+N+E (IP44)/ 32A/ 230V/ 7.3kW capacity
- Three-year warranty is extendable to five years if unit is registered within 120 days of purchase
