ATEN VP2730 7 x 3 seamless presentation matrix switcher

ATEN VP2730. Video port type: HDMI. Product colour: Black, Material: Metal, Supported video modes: 1080p. AC input voltage: 100 - 240 V, AC adapter frequency: 50 / 60 Hz, AC adapter input current: 1 A. Width: 432.4 mm, Depth: 262.8 mm, Height: 44 mm. Quantity per pack: 1 pc(s), Cables included: AC

https://www.aten.com/us/en/products/professional-audiovideo/presentation-switches/vp2730/

VP2730 is a multi-in-one presentation switch that integrates video matrix switch with scaler, streaming, audio mixer, HDBaseT extender, and analog-to-digital converter functions into one compact device. With seven multi-format inputs to two HDMI and one HDBaseT high-definition outputs, VP2730 empowers larger meetings and facilitates collaboration between local and remote participants in boardrooms, video conferencing rooms, lecture halls or distance learning classrooms.

With the user in mind, VP2730 comes with a straightforward and accessible OSD and Web GUI to streamline operation for both local and remote participants. To facilitate sharing and collaboration with no distance limitations, VP2730 not only allows the meeting moderator to share video content to up to five remote sites, but also enables remote sites or local participants to wirelessly stream in their content for discussion. The moderator can monitor and switch among sources in any variation of full-screen, dual-view, tri-view, quad-view or PIP modes, with up to six sources displayed simultaneously on one screen.

VP2730 also features more advanced meeting management functions: Moderator Mode enables the meeting moderator to control other displays via the host display; Chat Room facilitates meeting communications; while Screen Capture and Freeze record and control the meeting flow. This Collaborative presentation solution facilitates distance-free content sharing along with advanced audio, simplifying AV integration via eliminating the need for numerous individual components and the compatibility challenges that accompany them.

• Seamless Multi-format AV Switching
• 1080p Streaming for Distance-free Sharing and Collaboration
• Go Live – meeting moderator can broadcast HD video streams to up to 5 remote locations
• Streaming In – remote locations can stream and share content to the meeting moderator at any distance via intuitive web GUI
• Streaming Queuing – shares the streamed-in content approved by the meeting moderator one at a time to help manage the meeting flow
• Audio Mixer Integration for Advanced Applications
• Audio Mixer – allows mixing of the microphone inputs to any external analog or digital audio output device
• Embed/De-embed Audio – HDMI/DisplayPort audio signals can be extracted to separate digital/analog audio signals; Mic/Line audio can be embedded to HDMI audio
• Supports multi-format digital/analog audio outputs, including coaxial, TOSLINK and RCA
• Advanced Conferencing Management Features for Collaboration
• Multi-view – displays and switches simultaneously in any variation of full-screen, dual-view, tri-view, quad-view or PIP modes, with up to six sources displayed simultaneously on one screen
• Supports multi-format 7 Inputs:
• Moderator Mode – enables the meeting moderator control other displays via host display
• Chat Room – facilitates real-time and precise communication among remote participants
• Screen Capture – captures anything on your screen with a click
• Freeze – freezes the screen for discussion or to control the meeting flow
• Streamlined Operation
• View and control via ATEN Video Presentation Control App in a swift and agile way
• Multiple Control Options – flexible control via built-in Web UI, Front Panel, OSD, IR Remote Control, and RS-232, and Mobile App
• Auto switching – automatically detects and switches to a new source as soon as it is connected for time-saving and convenience
• • 2 combo inputs (HDMI/VGA, HDMI/DisplayPort)
• • 3 HDMI inputs
• 2 HDMI and 1 HDBaseT outputs
• Superior video quality up to 1080p @ 60Hz (HDMI/DisplayPort)
• Ultra Seamless Switchâ„¢ – zero second switching that provides continuous video streams, real-time switching and stable signal transmissions
• Scaler – features a video scaling function to convert input resolutions to the optimum display resolutions
• Flexible aspect ratio conversion
