FSP FlexGURU FSP250-50FGBBI(M) - Power supply (internal)
FLEX ATX - Active PFC - ATX 20+4 - 4+4 PIN - SATA x 4 - Molex x 2 - Floppy - FlexATX 1.22 - AC 100-240 V - 250 Watt - active PFC
Brand: FSP
SKU: PPA2500700
$0.00
Price as listed. Shipping charges calculated at checkout.
Out of stock
Do you have any question about this product or its specs? Want to know more? Click here to contact our pre-sales consultant and make the right purchase.
NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
General
Total power
250 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Motherboard power connector
20+4 pin ATX
Purpose
PC
Power supply unit (PSU) form factor
Flex ATX
Bearing technology
Ball bearing
Product colour
Black
Fan diameter
4 cm
Width
40.5 mm
Depth
150 mm
Height
81.5 mm
FSP/Fortron FlexGURU. Total power: 250 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX. Purpose: PC, Power supply unit (PSU) form factor: Flex ATX, Bearing technology: Ball bearing. Product colour: Black, Fan diameter: 4 cm. Width: 40.5 mm, Depth: 150 mm, Height: 81.5 mm
| Estimate Gross Weight | 0.968 |
|---|
https://www.fsplifestyle.com/en/product/Flexguru250W.html
FSP's FlexGURU Flex ATX models are available in standard direct output and modular cable configurations, which includes the most updated modular model selections in the market. The modular design improves the ease of nstallation, users can configure their connector cables according to the system needs. The special plug-in design for cables and jacks improves the convenience of replacement. Fully modular connectors allow users to quickly disassemble cables, pinpoint issues and save debugging time whenever the system experiences problems.
Fully Modular Design
Fully modular design with all black ribbon cables simplifies installation and allows you to use only the cables you need, for a neater and mechanical build.
High Power Density
Flexguru series featured with high power density, 20% higher than any Flex PSU in same wattage and frame.
Firm Installation with Beetle Technology
Standing out from FLEX-ATX PSU marketing, FSP pioneered the development of Beetle technology for FlexGuru series, strengthening the fixation adequacy by 25% to fit in most of the Flex-ATX chassis.
Excellent Thermal Performance
Differ from the genernal FLEX PSU, Flexguru series with inner 40mm fan design block the noise and achieve maximum cooling at all times.
85% Efficiency Conversion
The efficiency of your power supply is important because it directly affects you system’s performance. Flexguru 300W has a guaranteed typical efficiency of 90%, offer the high conversion power to power your system.
Keep in Compliance IEC 62368
FSP Group features the latest in green power technology, and provide a full kinds of additional safety approvals to keep designs ahead of the changing regulations. FSP has upgraded the majority of power supplies to the new IEC 62368 standard for your system.
Safety Protection
OVP (Over Voltage Protection), UVP (Under Voltage Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection), a full guardian circuit protections to keep your hardware safe.
100% Japanese Electrolytic Capacitors
Using Japanese electrolytic capacitors, Flexguru series offers the stable output and long-term reliability you need.
FSP's FlexGURU Flex ATX models are available in standard direct output and modular cable configurations, which includes the most updated modular model selections in the market. The modular design improves the ease of nstallation, users can configure their connector cables according to the system needs. The special plug-in design for cables and jacks improves the convenience of replacement. Fully modular connectors allow users to quickly disassemble cables, pinpoint issues and save debugging time whenever the system experiences problems.
Fully Modular Design
Fully modular design with all black ribbon cables simplifies installation and allows you to use only the cables you need, for a neater and mechanical build.
High Power Density
Flexguru series featured with high power density, 20% higher than any Flex PSU in same wattage and frame.
Firm Installation with Beetle Technology
Standing out from FLEX-ATX PSU marketing, FSP pioneered the development of Beetle technology for FlexGuru series, strengthening the fixation adequacy by 25% to fit in most of the Flex-ATX chassis.
Excellent Thermal Performance
Differ from the genernal FLEX PSU, Flexguru series with inner 40mm fan design block the noise and achieve maximum cooling at all times.
85% Efficiency Conversion
The efficiency of your power supply is important because it directly affects you system’s performance. Flexguru 300W has a guaranteed typical efficiency of 90%, offer the high conversion power to power your system.
Keep in Compliance IEC 62368
FSP Group features the latest in green power technology, and provide a full kinds of additional safety approvals to keep designs ahead of the changing regulations. FSP has upgraded the majority of power supplies to the new IEC 62368 standard for your system.
Safety Protection
OVP (Over Voltage Protection), UVP (Under Voltage Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection), a full guardian circuit protections to keep your hardware safe.
100% Japanese Electrolytic Capacitors
Using Japanese electrolytic capacitors, Flexguru series offers the stable output and long-term reliability you need.
- Compliant with the latest Flex ATX V1.22
- Intel latest CPU ready
- Complete protections: UVP, OVP, SCP, OPP, OTP
- 300W : Efficiency ? 90% at typical load
- 250W : Efficiency ? 85% at typical load
- Compliant with UL/EN/IEC 62368-1 and 60950 International safety standards
- Intelligent fan speed control
- Quiet and long-lasting 40mm ball bearing fan
- Ribbon cables for the need of enthusiasts
- Powerful single +12V rail design
- Main Japanese electrolytic capacitors
